Stainless Steel Guide Vane High Head Water Turbine with 1000RPM for 180 M Water Head Hydroelectric Generator
Detalhes do produto:
| Marca: | Wawushan |
| Certificação: | ISO9001 |
| Número do modelo: | T-202508 |
Condições de Pagamento e Envio:
| Quantidade de ordem mínima: | 1 |
|---|---|
| Preço: | 50000 |
| Detalhes da embalagem: | Padrão |
| Tempo de entrega: | 6 meses |
| Termos de pagamento: | T/T |
| Habilidade da fonte: | 100 conjuntos por ano |
|
Informação detalhada |
|||
| Palavra-chave: | Turbina de água de cabeça alta | cata-guia: | Aço inoxidável |
|---|---|---|---|
| Freqüência: | 50 Hz/60 Hz | cabeça da água: | 180 m |
| Tipo: | Turbina Hidráulica | diâmetro do corredor: | 1,0 m |
| Sistema de controle: | Excitação sem escova | Rotação: | 1000rpm |
| Destacar: | Stainless Steel Guide Vane High Head Water Turbine,1000RPM Hydroelectric Generator,180 M Water Head Hydraulic Turbine |
||
Descrição de produto
Stainless Steel Guide Vane Bulb Generator
High-performance 1000RPM hydroelectric power generator specifically designed for river and dam installations, delivering reliable energy conversion in demanding environments.
Product Overview
The High Head Water Turbine is an advanced hydroelectric solution engineered to efficiently harness energy from high head water sources. Operating within a power range of 1400 to 2200 KW, this turbine delivers optimal performance for medium to large-scale hydroelectric power plants with robust construction and innovative design.
Key Features
- Product Name: High Head Water Turbine
- Frequency: 50Hz/60Hz
- Phase Type: 3Phase/1Phase
- Runner Material: Stainless Steel
- Type: Hydraulic Turbine
- Head Range: 50-700 Meters
- Compatible with bulb generator systems
- Efficient bulb turbine generator design
- Supports tubular generator integration
Technical Specifications
| Parameter | Specification |
|---|---|
| Operating Temperature | -10°C To 50°C |
| Power Range | 1400-2200 KW |
| Phase Type | 3Phase/1Phase |
| Model | XJ02-W-50/1*11 |
| Runner Diameter | 1.0 M |
| Frequency | 50Hz/60Hz |
| Guide Vane | Stainless Steel |
| Head Range | 50-700 Meters |
| Type | Hydraulic Turbine |
Design Advantages
The turbine features a striking blue finish and incorporates a stainless steel runner that provides excellent corrosion and wear resistance. Operating at 1000 RPM with a 1.0 meter runner diameter, it maintains mechanical stability while maximizing energy conversion efficiency.
Compatibility & Integration
This versatile turbine integrates seamlessly with various generator types including axial flow turbines, bulb generators, and tubular generators. The axial flow design minimizes hydraulic losses while bulb generator compatibility offers compact, streamlined operation.
Applications
- Mountainous regions with significant elevation differences
- Small to medium-sized hydroelectric power stations
- Remote manufacturing plants and mining operations
- Agricultural processing facilities
- Off-grid and isolated communities
- Modernization projects for existing facilities
Customization Options
Wawushan offers comprehensive customization for the T-202501 model, including head range adjustments (50-700 meters), stainless steel guide vanes, and configuration with bulb, tubular, or tubular generator setups.
Support & Services
Our technical support program includes expert installation guidance, routine maintenance, troubleshooting assistance, technical documentation, training sessions, and genuine replacement parts to ensure optimal performance and reliability.
The High Head Water Turbine represents a reliable, efficient investment for sustainable energy production, combining durable materials with advanced technology for superior hydroelectric power generation.
